Welcome to this website where you can access the operator manuals for your Case 1042 and 1052 Draper Headers. This set of manuals has been written for both the owner and service representative to provide you with comprehensive information on the proper use and repair of your equipment. You'll find everything you need to maintain, repair, and use your device throughout its lifetime. The manual is divided into three parts and provides detailed information about each section of the Case draper header models.
This guide includes a complete list of technical information, troubleshooting instructions, step-by-step maintenance procedures, diagnostic procedures, specifications, and setting information. Illustrations, tables, schemes, and diagrams are provided to help you better understand the text and visually examine the parts of your draper headers. We highly recommend reading the security section in detail and taking care when performing any procedure. It's crucial not to operate or permit anyone to operate or service the machine until you or other persons have read this manual.
Please note that the machine should only be used for the applications and purposes described in this manual. Unauthorized modifications may result in serious injury or death. To view and print the necessary information, we recommend installing the Adobe PDF Reader program.
TABLE of CONTENTS:
Hydraulics
How it works
Pump Drive Gearbox-Combine Adapter
Draper, Reel, and Auger Drive Motor
Flow Control Valve - Combine Adapter
Sickle Drive Wobble Box
Feed Auger, Reel, and Draper Drive Hydraulic Pump
To the owner
Identification Number/Machine components
Safety/Decals
Controls/Transporting/Connections
Field Operation
Troubleshooting
Lubrication
Maintenance/Adjustments
Storage
Specifications
Detail index
