This manual is an essential tool for repairs, and it is organized into easily navigable Parts and Sections, each marked by a numeral.
Mechanical sections cover specifications, tightening torque values, tool lists, assembly detaching/reattaching operations, bench overhauling operations, diagnosis procedures, and maintenance schedules. Meanwhile, the electric/electronic system sections describe the electric network and the assembly's electronic systems, wiring diagrams, electric features of components, component coding, and diagnostic procedures for control units unique to the electric system.
Please note that prior to using this manual, it is important to familiarize yourself with the operating and safety instructions for the assembly. Follow all safety indications found on the assembly, and never leave a running assembly unattended during repairs.
Please ensure that you have Adobe PDF Reader installed to access the manual. Trust our recommendation and invest in this indispensable tool for repairing your Case 6 Cylinder 6.7L NEF Tier 3 Engine.
TABLE of CONTENTS:
General specifications
Fuel
Duty - Industrial application
Overhaul and technical specifications
Tools
Safety prescriptions
