Kubota BH77 Workshop Manual — 9Y121-05440

About this manual

Kubota published this Workshop Manual for the BH77 backhoe models. It brings the documented service and technical-reference material for those named backhoes into a single publication.

Use the Manual Contents below to check that the exact repair, inspection, or maintenance procedure you need is included in this publication.

Manual details

Manufacturer

Kubota

Manual type

Workshop Manual

Models

BH77

Document number

9Y121-05440

Publication year

2010

Language

English

Page count

75

Product highlights

Special tools

A special-tools section is included.

Manual contents

Use these source headings to locate the task or system you need in the PDF.

• 1. SAFETY FIRST — p. I-1
• 2. SAFETY DECALS — p. I-4
• 3. TERMINOLOGY — p. I-6
• 4. SPECIFICATIONS — p. I-7
• BACKHOE IDENTIFICATION — p. G-1
• GENERAL PRECAUTIONS — p. G-2
• LUBRICANTS — p. G-3
• TIGHTENING TORQUES — p. G-4
  • [1] GENERAL USE SCREWS, BOLTS AND NUTS — p. G-4
  • [2] STUD BOLTS — p. G-4
  • [3] AMERICAN STANDARD SCREWS, BOLTS AND NUTS WITH UNC OR UNF THREADS — p. G-5
  • [4] PLUGS — p. G-5
  • [5] HYDRAULIC FITTINGS — p. G-5
    • (1) Adaptors, Elbows and Others — p. G-5
• MAINTENANCE CHECK LIST — p. G-6
• CHECK AND MAINTENANCE — p. G-7
  • [1] CHECK POINTS OF EACH USE OR DAILY — p. G-7
  • [2] CHECK POINT OF EVERY 10 HOURS — p. G-9
• SPECIAL TOOLS — p. G-10

Capabilities

The source outline indexes checking and adjustment and maintenance tasks. Use these source-backed headings to locate the applicable task or system in the source PDF, then confirm model-specific notes, specifications, illustrations, and operating conditions at the relevant page before carrying out service work.

Keep the source's safety sequence, prerequisite steps, labels, units, configuration notes, and footnotes with the selected task; do not apply an isolated value outside the conditions stated in the manual.

Delivery

This manual is supplied as a digital PDF file and is available for instant download after purchase. No physical media is shipped.

References

Kubota Workshop Manual for Backhoe, document code 9Y121-05440, PDF edition.
